Harris model 447-200-CR single-stage high-flow back-entry station regulator, 200 PSI, using flammable gases other than oxygen
The Harris Model 447 heavy-duty, high flow, back entry station regulator is designed to deliver high gas flows from piping systems that are equipped with station regulator connection. This heavy-duty, high flow, station regulator has back entry access and a 7/8 in. - 14 C-inlet connection. Features include brass body and bonnet, 2.5 in. brass-plated steel dual scale gauge, brass T-screw adjusting handle and one-piece encapsulated seat design with internal filter and PTFE Teflon® seat.
Features
- Provides high gas flows for piping systems
- Designed to work with back-entry station regulator connections
- Forged brass body and bonnet for longer service life
- 2.5 in. brass-plated steel dual scale easy-to-read gauges (psi/kPa)
- Easy-to-operate brass T-screw adjusting handle
- Rubber diaphragm for greater sensitivity and improved pressure control
- One-piece encapsulated seat design with an internal filter to protect the PTFE Teflon® seat from particulate contamination
- Conforms to CGA E-4 standard for gas pressure regulators
- 7/8 in. - 14 RH (F) - 024 C-inlet connection
- 9/16 in. - 18 RH outlet connection
