Magnum PRO Robotic Air-Cooled Robotic Torch for Fanuc M710iC/12L Arms combines a robust design with industry-leading expendable parts to produce a consistent high performing arc.
Key Features
- Single Tool Center Point (TCP) - Changing between 350A and 550A expendables does not alter the robot TCP.
- Robust Cable System - Cables exceed industry standards by a factor of two in durability testing.
- Simplified Expendable Parts Selection - 350A and 550A rated consumables are interchangeable across all gun models.
- HexConnect Gun Bushing - Ensures better electrical conductivity through full face contact as opposed to rotating connections that have single line contact.
- Extended Reach - Mounting bracket is designed to optimize clearance for tough to reach welding applications.
What's Included
(1) Cable Assembly, (1) KP2920-4 Breakaway Disk, (1) K4308-3 Robotic Torch Housing with Air Blast, (1) K4307-1 Nose Cone, (1) KP3355-45 Thru-Arm Gooseneck (Binzel) 45⁰, (1) KP2743-1-62R 550A Recessed Nozzle 5/8 in, (1) KP2747-1 550A Diffuser, (1) KP2773-1 550A Insulator, (10) KP2745-045 550 A Contact Tips 0.045 in, (1) KP45-3545-15 15 ft Cable Liner .035-.045 in
Specifications
| Family Name | Fanuc |
| Warranty Length | 90 Days |
| Cooling | Air |
| Accessory Type | Thru-Arm |
| Weight | 15 lb. |
