Lincoln Classroom Pak - Teaching Aid Toolbox - K4442-1

WELDING TRAINING, UP CLOSE AND PERSONAL Curriculum in a CabinetComprehensive array of tools and accessories from various welding and cutting processesCutaway Harris gas regulator and oxyfuel torch allow students to get familiar with the tool's structure, operation and applicationBuild on the BasicsThe Teaching Aid Toolbox is fully supported with Lincoln Electric U/LINC curriculum lesson plans and moreBridge the Classroom and the LabBring actual welding and cutting tools into the classroom to better illustrate the principles of each processBoosts learning to the next level of understanding by illustrating joints, cuts, equipment and related techniquesIncluded weld sample coupons allow instructors to illustrate various welding joints and typical beadsA set of weld discontinuity flashcards allow you to show and discuss common weld flaws

Key Features

• Comprehensive array of tools and accessories from various welding and cutting processes
• Cutaway Harrisgas regulator and oxyfuel torch allow students to get familiar with the tool's structure, operation and application
• Fully supported with Lincoln Electric U/LINC curriculum lesson plans and more
• Bring actual welding and cutting tools into the classroom to better illustrate the principles of each process
• Boosts learning to the next level of understanding by illustrating joints, cuts, equipment and related techniques
• Drawer 5-Weld Samples: Butt Joint - 2 x 6 in. (50.8 x 152.4 mm) 10ga, Corner Joint - 2 x 6 in. (50.8 x 152.4 mm) 10ga, Edge Joint - 2 x 6 in. (50.8 x 152.4 mm) 10ga, Lap Joint - 2 x 6 in. (50.8 x 152.4 mm) 10ga, Tee Joint - 2 x 6 in. (50.8 x 152.4 mm) 10ga, Three Pass T Joint 100/75/50, 1/4 x 3 x 8 in. (6.35 x 76.2 x 203.2 mm), 1/4 x 3 x 8 in. (6.35 x 76.2 x 203.2 mm), 3/8 x 8 x 7 in. (9.53 x 203.2 x 177.8 mm), Discontinuities Flash Cards

What's Included

DRAWER 1 - SMAW|T300 Electrode Holder|EH-305HD Magnum Electrode Holder|200A Electrode Holder|GC-300 Work Clamp|3/32 in. (2.4 mm) Bare Stick Electrode Rod|1/8 in. (3.2 mm) Bare Stick Electrode Rod|5/32 in. (4.0 mm) Bare Stick Electrode Rod|Excalibur 7018 MR 3/32 in. (2.4 mm) 1 lb Tube Stick Electrode|,DRAWER 2 - GTAW|PTA-17V Torch Body|PTA-17V Torch Body|PTA-17F Torch Body|PTA-17 Torch Handle|PTA-17 3/32 in. (2.4 mm) Collet|PTA-17 3/32 in. (2.4 mm) Collet Body|PTA-17 Backcap- Long|PTA-17 Alumina Nozzle #6|GLK-3 Basic TIG Kit|,DRAWER 3 - GMAW / FCAW|Magnum PRO 550 Assembly|Magnum PRO 250L Assembly|Flux-Cored/MIG Wire Drive Roll 0.035 - .045 in. (0.9 - 1.1 mm) Knurled|Drive Roll Kit Combination 0.035/.045 in. (0.9-1.1 mm) Solid Wire Smooth|Magnum PRO MIG Gun Diffuser- 550A- Slip-On|Magnum PRO Gas Nozzle 550A- Slip-On- Flush- 3/4 in. ID|Magnum PRO Gas Nozzle 350A- Thread-On- Flush- 1/2 in. ID|Magnum PRO Gas Nozzle 350A- Thread-On- Recessed- 1/2 in. ID|Magnum PRO Bottleneck Gas Nozzle 350A- Thread-on- Flush- 1/2 in. ID|Magnum PRO Gas Nozzle 350A- 1/8 In. Stickout- Thread-on- 1/2 in. ID|Magnum PRO Gas Nozzle 350A- Flush- Thread-On- 3/8 in. ID|Magnum PRO MIG Gun Diffuser- 350A- Slip-On|Magnum PRO Gas Nozzle 350A- Flush- Slip-On- 1/2 in. ID|Magnum PRO MIG Gun Diffuser- 350A- Extended Reach- Thread-On|Magnum PRO Gas Nozzle 350A- Extended Reach- Thread-On- Recessed- 1/2 in. ID|Magnum PRO Contact Tip 550A- 0.035 in Dia.|Magnum PRO Contact Tip- 350A- Tapered- 0.035 in Dia.|Magnum PRO 350 Gas Diffuser Thread-On|Magnum PRO Barrel 550 Nozzle Assembly 550A- Thread-On-|Recessed- 5/8 in. ID|Magnum PRO MIG Gun Diffuser- 550A- Thread-On|,DRAWER 4 - CUTTING|Tomahawk LC40 Plasma Cutting Torch Assembly|Tomahawk LC40 Electrode|Tomahawk LC40 Swirl Ring|Tomahawk LC40 Nozzle (40 A)|Cutaway Harris Oxyfuel Torch|Cutaway Harris Gas Regulator|Acetylene Heating Assembly|Acetylene Two-Piece Preheat Tip|Cutting Tip|,DRAWER 5 - WELD SAMPLES|Butt Joint - 2 x 6 in. (50.8 x 152.4 mm) 10ga|Corner Joint - 2 x 6 in. (50.8 x 152.4 mm) 10ga|Edge Joint - 2 x 6 in. (50.8 x 152.4 mm) 10ga|Lap Joint - 2 x 6 in. (50.8 x 152.4 mm) 10ga|Tee Joint - 2 x 6 in. (50.8 x 152.4 mm) 10ga|Three Pass T Joint 100/75/50 -1/4 x 3 x 8 in. (6.35 x 76.2 x 203.2 mm)|6 Pass Groove 100/83/66/50/33/16 -3/8 x 8 x 7 in. (9.53 x 203.2 x 177.8 mm)|Discontinuities Flash Cards
