Lincoln Ranger Air 260MPX Multi-Function Engine Drive K5238-1

Designed for work truck operators who deal with the unexpected every day, this versatile machine delivers five key functionalities: Air Compressor, Generator, Battery Jump Assist, Battery Charge, and Multi-Process Welder.

Versatility With Unparalleled Performance

The Ranger Air 260MPX multi-function engine drive was designed for the operator who faces the unexpected every day.

VERSATILITY

5 key functionalities in one compact unit:
• Air Compressor
• Generator
• Battery Jump Assist
• Battery Charge
• Multi-Process Welder

INDUSTRY LEADING PERFORMANCE

Top-tier performance across the board for:
• Air Power
• Clean Auxiliary Power
• Arc Performance

LOWER COST OF OWNERSHIP

Integrated technology helps lower fuel and maintenance costs:
• Variable Engine Speed
• Auto Stop/Start

KEY FUNCTIONALITIES

AIR COMPRESSOR
The Vanair® rotary screw air compressor delivers instant 40CFM @150 PSI, generating up to 30% more air power compared to other machines in its class.
Operators can power large tools – up to a 1-inch impact wrench, and inflate
tires faster to complete jobs in less time.

GENERATOR
9KW of clean continuous AC generator power accommodates a variety of tools
and equipment, allows you to power tools while welding and with less than
5% total harmonic distortion (THD) you can operate sensitive electronics, like
laptops.

BATTERY JUMP ASSIST AND BATTERY CHARGE
Capability to jump and charge 12V and 24V batteries on the jobsite. Get
equipment started and keep productivity high with 260A for cold cranking assist.

MULTI-PROCESS WELDER
Stick, TIG, MIG, Flux-Cored and direct connect spool gun
with a 260A/26V/100% duty cycle so the operator can tackle a variety
of applications.

KEY FEATURES

» Be Ready for any Challenge - Multi-Function capabilities allow operators to take on a variety of projects

» Free Up Space and Increase Available Payload - Compact design allows for additional tools and equipment.

» Save Time - Digital user interface makes setup quick and easy

» Tackle Welding with Ease with integrated Ready. Set. Weld.® and Chopper Technology®

» Avoid Costly Repairs - Maintenance alerts notify operator when service is needed

» Save Money - Variable Engine Speed and Auto Stop/Start technology help lower
