Lincoln MAXsa 22 Submerged Arc Hard Automation Feed Head - K2370-2

Lincoln MAXsa 22 Submerged Arc Hard Automation Feed Head - K2370-2

By: Lincoln Electric
SKU:
K2370-2
$8,037.00
$8,319.95
(You save )
Current Stock:
Adding to cart… The item has been added

Submerged Arc Hard Automation Feed Head

Designed specifically for hard automation applications, the MAXsa 22 Feed Head delivers accurate wire feeding of large diameter submerged arc wires. Based on Lincoln Electric's proven gearbox and cast aluminum feedplate, the MAXsa 22 model features a 40VDC permanent magnet, high torque motor that delivers plenty of traction to push up to 7/32 in. (5.6 mm) diameter solid wire. A top speed of up to 500 ipm (12.7 m/min) can be achieved by changing the gear ratio.

Features

  • Flexible Configuration - Can be used in single, tandem, Twinarc, or multiple arc applications.
  • Closed Loop Speed Control - Facilitates full control over starting, running, and stopping wire feed speed.
  • Wide Range of Wire Feed Speed – Gear ratio conversion kits allow for a wide range of WFS capabilities to match the requirements of your application.
  • Rotatable feed head allows flexible, accurate setup for fixturing.
  • Standard Accessories – Including an adjustable wire straightener, cross-seam adjuster, electrical valve flux hopper, and mounting bracket for TC-3 carriage.

What's Included

  • MAXsa 22 Feed Head
  • Adjustable Wire Straightener
  • Cross-Seam Adjuster
  • Electric Flux Hopper
  • Mounting Bracket for TC-3 Carriage
