Lincoln HyperFill Reveal Power Feed 84 Dual Ready-Pak, Dual Cart - K4650-6

Twin wire productivity with single power source simplicity all packaged in a convenient Ready-Pak

Twin Wire MIG Productivity Without Complexity

Designed to revolutionize heavy fabrication productivity, the patented HyperFill® twin wire MIG solution allows for increased deposition rates without compromising puddle stability or weld quality. Utilizing a single power source, a single wire feeder, a single tip, and Lincoln Electric premium wire, this innovative solution delivers a wide, smooth arc cone that allows for deposition rates above 18 lbs./hr. | 8.2 kg/hr. (24 lbs./hr. | 10.9 kg/hr. robotic) without added system or operator complexity.

Features

• Convenient Ready-Pak - Comes ready to weld within minutes!
• Dual Process Ready - Run HyperFill and a single wire process on the same system
• Advanced Connectivity - All Power Wave systems come standard with access to Lincoln Electric Power Wave Manager and Lincoln Electric Checkpoint Production Monitoring allowing for advanced remote configuration, process control, and quality assurance.
• Compact and Durable - IP23 rated to withstand harsh environments.
• Patented PowerConnect Technology - Automatically adjusts to input power from 200-600V, 50 or 60 Hz, single phase or three phase. Welding output remains constant through the entire input voltage range.
• Tribrid Power Module - Exceptional welding performance with high power factor and efficiency.
• 115V (10A) AC Duplex Auxiliary Power Receptacle - Features Surge Blocker Technology to ensure simultaneous welding performance is not compromised by high starting current devices such as grinders (typically requiring 60A or more peak surge current).
• Smart Fan Operation - Only runs when needed to minimize noise and energy consumption.
• Solution Requirements » HyperFill is a patented and licensed twin-wire MIG solution that is designed to perform specifically with select Lincoln Electric welding wire. The solution requires a licensed waveform which may require an additional purchase. For more details, reference document MC20-106.
• Industry Leading 5 Year Warranty

What's Included

• Model 355-2Ar/Co2-58010 Flowmeter Regulator Shielding Gas Kit | 3100856
• Cart for Inverter and Wire Feeder | K3059-4
• Cable Liner 1/16 - 5/64 in (1.6 - 2.0 mm), 15 ft (4.6 m) | KP44-564-15
• Weld Power Cable - Lug to Lug (3/0, 600A, 60%) - 10 ft. (3 m) | K1842-10
• Work Lead - Lug & GC500 Ground Clamp (4/0, 600A, 60%) - 15 ft. (4.6 m) | K2149-1
• Magnum PRO Water-Cooled Gas Nozzle - Thread-On, 1/8 in Recess, 3/4 in ID | KP4523-1-75R
• Wire Reel Stand - Standard Duty | K3342-1
• Gateway Pendant | K4997-1
• HyperFill Diffuser | KP4481-1
• Magnum PRO Curve 300 Welding Guns | K2951-2-10-45
• M-F Quick Disconnect Water Hose Kit (7 ft.) | K4544-7
• Cool Arc 55 S Water Cooler | K3086-2
• Incoming Ball Bearing Bushing for Lincoln Conduit | K1551-2
• Power Wave S500 Advanced Process Welder | K2904-1
• Drive Roll Kit 0.040 - 0.045 in (1.0 - 1.1 mm) Solid Wire | KP1505-045S
• Magnum PRO 500 Water Cooled Welding Guns | K4522-2-10-564
• HYPERFILL Reel Stand Conversion Kit | K4630-1
• HYPERFILL Drive Roll Kit (0.035 - 0.040 in.) (0.9 -1.0 mm) | KP4388-1
• Power Feed 84 Dual Bench Wire Feeder - U/I, No Reel, USB | K3330-3
