Features
-
Deep arc penetration
-
Light slag with minimal arc interference
-
Excellent vertical and overhead capability
Typical Applications
-
Cross country and in-plant pipe welding
-
Steel with moderate surface contaminants
-
Square edge butt welds
-
Welding on galvanized and specially coated steels
Welding Positions
-
All positions
Shielding Gas
-
Not Applicable
CONFORMANCE
| CONFORMANCES |
|---|
| AWS |
| ISO |
| ABS |
| CWB |
| DNV-GL |
| SPECIFICATION | CLASSIFICATION |
|---|---|
| AWS A5.1 | E6010 |
| ISO 2560-A | E 42 3 C 2 5 |
| AWS A5.1 | E6010 |
| CSA W48 | E4310 |
| DNV - 2.9 | 3 |
MECHANICAL PROPERTIES
| Classification |
|---|
| E6010 Requirement |
| Typical Result, As-welded |
|
Yield Strength @ 0.2% Offset MPa (ksi) |
Tensile Strength MPa (ksi) |
Elongation % |
Charpy V-Notch J (ft-lbs) @ -30°C (-20°F) |
Hardness Rockwell B |
|---|---|---|---|---|
| 330 (48) min. | 410 (60) min. | 22 min. | 27 (20) min. | |
| 430-480 (62-69) | 530-580 (76-85) | 23-31 | 51-122 (38-90) | 82-91 |
DEPOSIT COMPOSITION
| Classification |
|---|
| E6010 Requirement |
| Typical Result |
| %C | %Cr | %Mn | %Mo | %Ni | %P | %S | %Si | %V |
|---|---|---|---|---|---|---|---|---|
| 0.20 max. | 0.20 max. | 1.20 max. | 0.30 max. | 0.30 max. | 1.00 max. | 0.08 max. | ||
| 0.12-0.16 | 0.06 max. | 0.50-0.67 | 0.02 | 0.07 max. | 0.007-0.012 | 0.004-0.011 | 0.14-0.25 | 0.01 |
TYPICAL OPERATING PROCEDURES
| Diameter |
|---|
| 3/32 in (2.4 mm) |
| 3/32 in (2.4 mm) |
| 1/8 in (3.2 mm) |
| 1/8 in (3.2 mm) |
| 5/32 in (4.0 mm) |
| 5/32 in (4.0 mm) |
| 3/16 in (4.8 mm) |
| 3/16 in (4.8 mm) |
| Polarity⁽¹⁾ |
Current Amps |
|---|---|
| DC+ | 50-85 |
| DC- | 50-85 |
| DC+ | 75-135 |
| DC- | 75-135 |
| DC+ | 100-175 |
