Model 247NC-15-1/4 in. (LH) economical medium duty back-entry single-stage pipeline regulator.
Model 247NC provides high gas flow for gas distribution systems. This heavy-duty, economically priced, pipeline regulator has back entry access and a 1/4 in. NPT (F) inlet connection. It features a brass body, chrome-plated zinc die-cast bonnet, 2 in. gold-painted steel dual scale gauge, brass T-screw adjustment, one-piece encapsulated seat design with internal filter and neoprene seat.
Features
- Economically priced back entry pipeline regulator
- Designed to provide high gas flows for gas distribution systems
- Brass body and chrome-plated zinc die-cast bonnet for longer service life
- Easy-to-operate brass T-screw adjusting handle
- 2 in. Gold painted steel dual scale easy-to-read gauge (psi/kPa)
- Rubber diaphragm for more sensitive pressure control
- One-piece encapsulated seat design with internal filter to protect the neoprene seat from particulate contamination
- One-piece encapsulated seat design with internal filter to protect the neoprene seat from particulate contamination
